Features
- Works at 1000Mbps in Full-Duplex mode for both TX port and FX port
- Supports auto MID/MID-X for TX port
- Provides switch configuration of Force /Auto transfer mode for FX port
- Extends fiber distance up to 15 km
- Easy-to-view LED indicators provide status to monitor network activity easily
- External power supply

Specifications
- Standards and Protocols: IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
- Basic Function:
* Full Duplex Flow Control (IEEE 802.3x)
* Extends fiber distance up to 15 km
- Ports:
* 1× 1000M SC port
* 1× 1000M RJ45 port (Auto MDI/MDIX)
- Network Media:
* 1000BASE-T - UTP category 5, 5e cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m)
* 1000BASE-FX - Single-mode Fiber
- LED Indicators: PWR, LINK, RX
- Safety & Emission: FCC, CE
- Dimensions (W×D×H): 94.5×73.0×27.0 mm
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
- Power Supply: External Power Adapter
