Dual Band WiFi 6
- Separate 5 GHz (2402 Mbps) and 2.4 GHz (574 Mbps) WiFi bands for faster speeds and greater capacity with the latest technology

Uninterrupted Streaming
- Easily create a TP-Link OneMesh network for seamless whole home WiFi coverage

AP Mode
- Create a new WiFi access point through the Gigabit Ethernet port to enhance your wired network with WiFi capability

Gigabit Ethernet Port
- Provides high-speed wired access, ideal for smart TVs, PCs, and game consoles

App Control
- Easy Setup and management with your network using the TP-Link Tether app

Specifications
WIRELESS
- Working Modes: Range Extender / Access Point

HARDWARE FEATURES
- Ports: 1 Gigabit Ethernet Port
- Button: WPS Button, Reset Button
- Input Power: 100-240V~50/60Hz
- Power Consumption: 12.6W
- Dimensions ( W x D x H ): 97*46*158
- Antenna: 2 External Antennas

WIRELESS FEATURES
- Wireless Standards: IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n/ax 2.4GHz
- Frequency: 2.4GHz and 5GHz
- Signal Rate: 574 Mbps at 2.4GHz, 2402 Mbps at 5GHz
- Working Modes: Range Extender / Access Point
- Reception Sensitivity
- 5GHz:
• 11a 6Mbps:-97dBm
• 11a 54Mbps:-78dBm
• 11ax HE20 MCS0: -97dBm
• 11ax HE20 MCS11: -66dBm
• 11ax HE40 MCS0: -94dBm
• 11ax HE40 MCS11: -62dBm
• 11ax HE80 MCS0: -91dBm
• 11ax HE80 MCS11: -61dBm
• 11ax HE160 MCS11: -59dBm

- 2.4GHz:
• 11g 6Mbps:-96dBm
• 11g 54Mbps:-78dBm
• 11ax HE20 MCS0: -95dBm
• 11ax HE20 MCS11: -66dBm
• 11ax HE40 MCS0: -93dBm
• 11ax HE40 MCS11: -62dBm

- Transmit Power: CE: 2.4GHz ?16dBm, 5GHz ?21dBm
- Wireless Modes: Range Extender / Access Point
- Wireless Functions: Enable/Disable Wireless Radio, Wireless Statistics
- Wireless Security: WEP, WPA, WPA2, WPA3
- Transmission Power: CE: 2.4GHz ?16dBm, 5GHz ?21dBm
- Mesh Technology: EasyMesh-Compatible

OTHERS
- Certification: CE, RoHS
- Package Contents:
• Wi-Fi Range Extender RE705X
• Quick Installation Guide
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux, Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
- Environment:
• Operating Temperature: 0?~40? (32? ~104?)
• Storage Temperature: -40?~70? (-40? ~158?)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
