Features
- TP-Links First 4G+ Router - supports 4G+ Cat6 to boost the data speeds of up to 300 Mbps
- Full Gigabit Ports - provides reliable wired connections for bandwidth-intensive devices such as game consoles and STB
- Plug a SIM card and play - no configurations needed, compatibility of SIM cards in 100+ countries are assured by years of field tests
- Better Signal for Connections Everywhere - enjoy stable and efficient connections to every device thanks to the two external LTE antennas
- Wi-Fi router mode - plug an Ethernet cable into the LAN/WAN port for flexible access as a backup option if you cant get a 4G connection
- Supports TP-Link OneMeshTM - co-works with TP-Link OneMesh products to create a flexible and cost-efficient Mesh network
Specifications
HARDWARE FEATURES
- Interface:
1× 10/100/1000 Mbps LAN/WAN Port
3× 10/100/1000 Mbps LAN Ports
1× Micro SIM Card Slot
- Button: WPS Button, Reset Button, WiFi On/Off Button, Power On/Off Button
- External Power Supply:
* Power Adapter: Input Power 100-240v, 50/60 Hz 0.6A
* Output parameter 12VDC / 1.5A
- Dimensions (W×D×H): 229×160×37 mm
- Antenna: 2× Detachable 4G LTE Antennas
WIRELESS FEATURES
- Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
- Frequency: 2.4 GHz and 5 GHz
- Signal Rate: 300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
- Reception Sensitivity:
* 5 GHz:
11a 54M: -74 dBm
11ac HT20: -66 dBm
11ac HT40: -63 dBm
11ac HT80 : -59 dBm
11n HT20: -73 dBm
11n HT40: -70 dBm
* 2.4 GHz:
11g 54M: -74 dBm
11n HT20: -72 dBm
11n HT40: -69 dBm
- Transmit Power: < 20 dBm (2.4 GHz), < 23 dBm (5 GHz)
- Wireless Functions: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
- Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
- Network Type:
* 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
* TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
* 3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)
SOFTWARE FEATURES
- Quality of Service: Bandwidth Control
- Security: DoS, IPv4 SPI Firewall, IPv6 Firewal, IP and MAC Address Binding, Access Control
- WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
- Management: TP-Link Cloud, Local Management, Remote Management
- DHCP: Server, DHCP Client List, Address Reservation
- Port Forwarding: ALG, Virtual Server, Port Triggering, UPnP, DMZ
- Dynamic DNS: TP-Link, DynDns, NO-IP
- VPN: PPTP VPN, IPSec VPN , OpenVPN
- Access Control: Parental Control, Local Management Control
- Firewall Security: DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding
- Protocols: IPv4, IPv6
- Guest Network:
1× 2.4 GHz Guest Network
1× 5 GHz Guest Network
OTHERS
- Certification: CE, RoHS
- Package Contents: 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router Archer MR600, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide
- System Requirements:
* Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
* Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
* Java-enabled browser
* Micro SIM Card
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
