Features
- Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode
- Supports MAC address auto-learning and auto-aging
- LED indicators for monitoring power, link, activity
- Plastic case, desktop or wall-mounting design
- External Power Adapter supply

Specifications
- Standards and Protocols: IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP
- Basic Function:
* Wire-speed Performance
* MAC Address Auto-Learning and Auto-aging
* IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode
- Backbound Bandwidth: 3.2Gbps
- MAC Address Table: 1k
- Forwarding Rate:
* 10BASE-T: 14880pps/port
* 100BASE-TX: 148800pps/port
- Transmission Method: Store-and-Forward
* Ports: 16× 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
- Network Media:
* 10Base-T: UTP category 3, 4, 5 cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m)
* 100Base-Tx: UTP category 5, 5e cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m)
- LED Indicators: Power, Link/Act (1-16)
- Safety & Emission: FCC, CE
- Dimensions (W×D×H): 200×142×40 mm
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
- Power: External Power Adapter
