+12V1: 30 A
, +12V2: 16 A
, +3.3V: 15 A
, +5V: 16 A
, +5VSB: 2.5 A (12.5 )
, -12V: 0.8 A (9.6 )
, 20+4-pin Main Connector: 1
, 4/8-pin +12V Power Connector: 1
, 4-pin Floppy Drive Connector: 1
, 4-pin Peripheral Power Connector: 2
, Box Weight Brutto (kg): 15 kg
, Cable Included: Power Cord
, Circuit Protection: Over Voltage Undervoltage Over Current Short Circuit Protection Over Power
, Depth (mm): 140 mm
, External Color: Gray
, Fan Diameter: 80 mm
, Fans Installed Quantity: 1
, Form Factor: ATX
, Height (mm): 86 mm
, Included Accessories: User GuideScrews
, Input Frequency: 50/60 Hz
, Input Power Connectors Quantity: 1
, Input Power Connectors Type: IEC-320 C14
, Input Voltage: AC 230 V
, Material: Metal
, Maximum Fans Supported Quantity: 1
, Maximum Output Power: 500 W
, Nominal Weight: 1.14 kg
, Output Voltage: DC 3.3/5/±12 V
, Pack Weight Brutto (kg): 1.5 kg
, Pack Weight Netto (kg): 1.14 kg
, Package Type: Box
, Packs in Box: 10
, Pieces in pack: 1
, Power Adapter and Power Supply Features: Automatic Fan Control
, Power Device Location: Plug-in-module
, Power Device Type: Power Supply
, Rated Current: 3 A
, Retail Packaging Net Weight Carton: 0.05 kg
, Retail Packaging Net Weight Plastic: 0.05 kg
, S-ATA Connector: 3
, Warranty Products Returnable: Yes
, Warranty Term (month): 24 month(s)
, Warranty validation Criteria: Serial Number
, Width (mm): 150 mm
